防火板用来隔墙具体方法?

来源:http://www.fumeijia.net/ 日期:2021-02-17
   今天针对防火板用来隔墙来说明下具体方法。
Today for the fire board used to partition to explain the specific method.
使用的具体步骤:
The specific steps are as follows:
1。防火板:一般建议采用厚度大于6mm的玻璃镁板作为隔断板。
1。 Fireproof board: it is generally recommended to use glass magnesium board with a thickness greater than 6 mm as partition board.
2.配件:6毫米以上的床单固定在车架的龙骨上。采用3.5200毫米的沉头螺钉固定,钉头在板面上下方0.5毫米处,确保光洁度光滑。
2. Accessories: the bed sheet over 6 mm is fixed on the keel of the frame. It is fixed with 3.5200 mm countersunk head screw, and the nail head is 0.5 mm above and below the board surface to ensure smooth finish.
3.安装:开始安装时,须标记并标记龙骨的确切位置。垂直龙骨之间的距离为450-600mm。墙壁和门窗侧面的接缝应安装额外的龙骨。如果墙的高度大于2440mm,则须在板的接头处安装支撑龙骨。
3. Installation: at the beginning of installation, mark and mark the exact position of keel. The distance between vertical keel centers is 450-600mm. Additional keels shall be installed at joints of walls and sides of doors and windows. If the height of the wall is greater than 2440 mm, the supporting keel shall be installed at the joint of the plate.
4。板间距:相邻板之间的间隙为4-6mm。板与地面之间的间隙须为5mm。螺钉安装距为150mm,距板边10mm,距板角30mm。
4。 Plate spacing: the gap between adjacent plates is 4-6mm. The gap between the board and the ground shall be 5mm. The screw installation center distance is 150 mm, 10 mm from the plate edge and 30 mm from the plate angle.
5.悬挂:悬挂厕所或厨房等重物时,须用木板或龙骨加固,以免损坏。
5. Hanging: when hanging heavy objects such as toilets or kitchens, they must be reinforced with wood or keel to avoid damage.
              富美家防火板
6.接缝处理:在安装过程中,板和板留有4-6mm的间隙。用107胶水或胶水混合后,用刮刀涂抹刀片和间隙,然后用纸带或造型胶带粘贴并压平。
6. Joint treatment: in the process of installation, there is a gap of 4-6mm between plates. After mixing with 107 glue or glue, smear blade and gap with scraper, then paste and flatten with paper tape or modeling tape.
7。油漆装饰:可采用喷涂、刷涂或滚涂,但刷涂时须参照油漆的有关说明。
7。 Paint decoration: spray painting, brush painting or roll painting can be used, but the relevant instructions of paint must be referred to when brushing.
8.装饰瓷砖:在浴室、卫生间、厨房、地下室等潮湿处安装时,面板上的瓷砖和龙骨之间的距离须缩短到400毫米。每三片墙(约3.6毫米左右)须有拉伸接缝。
8. Decorative tiles: when installing in wet places such as bathroom, toilet, kitchen and basement, the distance between the tiles on the panel and the keel must be shortened to 400mm. Every three walls (about 3.6 mm) shall have tensile joints.
9.隔音墙:如果墙体具有很高的隔音效果,墙壁和板材须紧密封闭,矿物棉应填入空墙。如果龙骨两侧由两个不同厚度的板制成,则隔室的效果更好。
9. Sound insulation wall: if the wall has a high sound insulation effect, the wall and board shall be closed tightly, and mineral wool shall be filled into the empty wall. If both sides of the keel are made of two plates of different thickness, the effect of the compartment is better.
10。防冲击墙:建议选用8毫米以上的防火板或单层防火板。第 二块板用较长的螺丝加固。该方法可提高材料的抗冲击、隔热、隔声、耐火性能。
10。 Anti impact wall: it is recommended to use more than 8 mm fireproof board or single-layer fireproof board. The second plate is reinforced with longer screws. This method can improve the impact resistance, heat insulation, sound insulation and fire resistance of the material.
